YESWELDER 250A Multi-Process Welder: up to 250 A, 110/220 V

What it welds

The YESWELDER 250A Multi-Process Welder is a multi-process with a maker-stated output of up to 250 amps on 110 or 220-volt input.

At its top output of 250 amps, Miller's 1-amp-per-thousandth rule points to about 1/4 in of steel per pass. Where the rule comes from.

The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.

Processes, per the maker: MIG/Flux Core/Spool Gun. Most multi-process machines' TIG is DC lift-arc, so no aluminium unless AC is stated. Choosing a process.

Running on 120 or 240 volts, it trades output for convenience on the lower input. What input voltage changes.

Use a lens of at least OSHA's minimum shade for the current: shade 10 or darker for typical MIG work here. Shade chart.

Also on the listing: a weight of 37.6 lb.

Is it the right machine for the job?

Buy it for

A shop that does a bit of everything
Steel to about 1/4 in per pass

Skip it for

Steel much past 1/4 in in one pass

What it does well, where it falls short

Does well

Up to 250 A output
Dual-voltage input
Multi-process
Pulse: Pulsed MIG

Falls short

Duty cycle not stated with amps
Torches may be extra

Power and setup notes

Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.

Rated output and specs

Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.

Model number	250A	Retailer
Product weight	37.6 lb	Retailer
Size	MIG-250PRO	Retailer
Material	MIG Welder 250A	Retailer
Power	ac	Retailer
Input power	110 volts, 220 volts	Retailer
Wattage	5.6 KW	Retailer
Output range	250a	Retailer
Processes	MIG/Flux Core/Spool Gun	Retailer
Pulse	Pulsed MIG	Retailer
Spool gun	Spool Gun	Retailer
