What it welds
The YESWELDER 185A Multi-Process Welder is a multi-process with a maker-stated output of up to 185 amps on 110 or 220-volt input.
Miller's starting rule, 1 amp for each 0.001 inch of steel, puts 185 amps at roughly 3/16 in of steel in one pass; thicker work means bevels and more passes. Run the amperage selector.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: MIG/Gas MIG/Spool Gun. Most multi-process machines' TIG is DC lift-arc, so no aluminium unless AC is stated. Choosing a process.
Running on 120 or 240 volts, it trades output for convenience on the lower input. What input voltage changes.
Use a lens of at least OSHA's minimum shade for the current: shade 10 or darker for typical MIG work here. Shade chart.
Also on the listing: a weight of 33.4 lb.
Is it the right machine for the job?
Buy it for
- A shop that does a bit of everything
- Steel to about 3/16 in per pass
Skip it for
- Steel much past 3/16 in in one pass
What it does well, where it falls short
Does well
- Up to 185 A output
- Dual-voltage input
- Multi-process
Falls short
- Duty cycle not stated with amps
- Torches may be extra
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | 185A | Retailer |
|---|---|---|
| Product weight | 33.4 lb | Retailer |
| Size | 17.83×8.46×14.17 in | Retailer |
| Material | MIG Welder 185A | Retailer |
| Power | ac | Retailer |
| Input power | 110 volts, 220 volts | Retailer |
| Wattage | 5.1 KW | Retailer |
| Output range | 185 Amp | Retailer |
| Processes | MIG/Gas MIG/Spool Gun | Retailer |
| Spool gun | Spool Gun | Retailer |
| Shielding gas | Gasless | Retailer |
Machines to put next to it
Other multi-process welders in the same amp range
- Weldpro 155GD Multi-Process Welder
- FEMEROL MTC200PRO Multi-Process Welder
- YESWELDER 205A Multi-Process Welder
- PUWU CT-418PRO Multi-Process Welder
Every multi-process welders on one spec sheet · All YESWELDER machines listed
Final verdict
Made for A shop that does a bit of everything.
