YESWELDER 165A Multi-Process Welder: up to 165 A, 110/220 V

What it welds

The YESWELDER 165A Multi-Process Welder is a multi-process with a maker-stated output of up to 165 amps on 110 or 220-volt input.

By Miller's rule of thumb of 1 amp per 0.001 inch of steel, 165 amps reaches about 0.165 in in a single pass. Amps by thickness.

The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.

Processes, per the maker: MIG/Gas MIG/Stick/Lift TIG. Check which torches and guns come in the box; a TIG torch or spool gun is often extra. Process guide.

Dual-voltage input gives portability on 120 volts and full output on 240; the maker's ratings for each input differ. 120 V vs 240 V.

Eye protection: OSHA's minimum is shade 10 for most of this machine's range (shade 10 for stick above 160 A). Full table.

Also on the listing: a weight of 25.8 lb.

Is it the right machine for the job?

Buy it for

A shop that does a bit of everything
Steel to about 0.165 in per pass

Skip it for

Steel much past 0.165 in in one pass

What it does well, where it falls short

Does well

Up to 165 A output
Dual-voltage input
Multi-process

Falls short

Duty cycle not stated with amps
Torches may be extra

Power and setup notes

Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.

Rated output and specs

Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.

Model number	165A	Retailer
Product weight	25.8 lb	Retailer
Size	16.93×8.11×13.78 in	Retailer
Material	MIG Welder 165A	Retailer
Power	ac	Retailer
Input power	110 volts, 220 volts	Retailer
Wattage	4.2 KW	Retailer
Output range	165 Amp	Retailer
Processes	MIG/Gas MIG/Stick/Lift TIG	Retailer
Shielding gas	Gasless	Retailer
