What it welds
The YESWELDER 160A Multi-Process Welder is a multi-process with a maker-stated output of up to 160 amps on 110 or 220-volt input.
Miller's starting rule, 1 amp for each 0.001 inch of steel, puts 160 amps at roughly 5/32 in of steel in one pass; thicker work means bevels and more passes. Run the amperage selector.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: MIG/Gas MIG/ Stick/Lift TIG. Check which torches and guns come in the box; a TIG torch or spool gun is often extra. Process guide.
Dual-voltage input gives portability on 120 volts and full output on 240; the maker's ratings for each input differ. 120 V vs 240 V.
Eye protection: OSHA's minimum is shade 10 for most of this machine's range (shade 10 for stick above 160 A). Full table.
Also on the listing: a weight of 27.5 lb.
Is it the right machine for the job?
Buy it for
- A shop that does a bit of everything
- Sheet metal to about 5/32 in
Skip it for
- Steel much past 5/32 in in one pass
What it does well, where it falls short
Does well
- Up to 160 A output
- Dual-voltage input
- Multi-process
Falls short
- Duty cycle not stated with amps
- Torches may be extra
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | 160A | Retailer |
|---|---|---|
| Product weight | 27.5 lb | Retailer |
| Size | 20.79 x 15.43 x 12.01 inches | Retailer |
| Material | Aluminum, Copper, Electronic Components, Insulation Materials, Iron, Plastic | Retailer |
| Power | dc | Retailer |
| Input power | 110 volts, 220 volts | Retailer |
| Wattage | 4.2 KW | Retailer |
| Output range | 160a | Retailer |
| Processes | MIG/Gas MIG/ Stick/Lift TIG | Retailer |
Machines to put next to it
Other multi-process welders in the same amp range
- ARCCAPTAIN 160A Multi-Process Welder
- YESWELDER FLUX-135PRO Multi-Process Welder
- ARCCAPTAIN 165A Multi-Process Welder
- FEMEROL MIG 250PRO Multi-Process Welder
Every multi-process welders on one spec sheet · All YESWELDER machines listed
Final verdict
A match for A shop that does a bit of everything.
