ARCCAPTAIN 205A DC TIG Welder: up to 205 A, 120 V

What it welds

The ARCCAPTAIN 205A DC TIG Welder is a DC TIG with a maker-stated output of up to 205 amps on 120-volt input.

By Miller's rule of thumb of 1 amp per 0.001 inch of steel, 205 amps reaches about 0.205 in in a single pass. Amps by thickness.

The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.

Processes, per the maker: ARC/Lift TIG. Most multi-process machines' TIG is DC lift-arc, so no aluminium unless AC is stated. Choosing a process.

It's DC TIG: steel, stainless and chromoly, but not aluminium.

Household 120-volt power caps its output; check the circuit size the manual asks for. What input voltage changes.

Use a lens of at least OSHA's minimum shade for the current: shade 8 or darker for typical TIG or stick work here. Shade chart.

Also on the listing: a weight of 14.52 lb.

Warranty, per the listing: 3 Years.

Is it the right machine for the job?

Buy it for

Steel and stainless TIG
Steel to about 0.205 in per pass

Skip it for

Steel much past 0.205 in in one pass
Aluminium

What it does well, where it falls short

Does well

Up to 205 A output
Runs on household 120 V

Falls short

Duty cycle not stated with amps
120 V caps output
No aluminium (DC only)

Power and setup notes

Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.

Rated output and specs

Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.

Model number	205A	Retailer
Product weight	14.52 lb	Retailer
Size	ARC205 Pro Stick Welder	Retailer
Power	Electric Corded	Retailer
Warranty	3 Years	Retailer
Output range	205 amps	Retailer
Input power	120v	Retailer
Processes	ARC/Lift TIG	Retailer
