TOOLIOM TL-200T DC TIG Welder: up to 200 A, 110 V

What it welds

The TOOLIOM TL-200T DC TIG Welder is a DC TIG with a maker-stated output of up to 200 amps on 110-volt input.

Miller's starting rule, 1 amp for each 0.001 inch of steel, puts 200 amps at roughly 0.200 in of steel in one pass; thicker work means bevels and more passes. Run the amperage selector.

The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.

It's DC TIG: steel, stainless and chromoly, but not aluminium. Pulse: pulse tig.

Household 120-volt power caps its output; check the circuit size the manual asks for. What input voltage changes.

Use a lens of at least OSHA's minimum shade for the current: shade 8 or darker for typical TIG or stick work here. Shade chart.

Is it the right machine for the job?

Buy it for

Steel and stainless TIG
Steel to about 0.200 in per pass

Skip it for

Steel much past 0.200 in in one pass
Aluminium

What it does well, where it falls short

Does well

Up to 200 A output
Runs on household 120 V
Pulse: pulse tig

Falls short

Duty cycle not stated with amps
120 V caps output
No aluminium (DC only)

Power and setup notes

Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.

Rated output and specs

Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.

Model number	TL-200T	Retailer
Material	Metal	Retailer
Model name	TIG Welder	Retailer
Output range	200a	Retailer
Input power	110v	Retailer
AC / DC	dc tig	Retailer
Pulse	pulse tig	Retailer
