What it welds
The ARCCAPTAIN MIG200P MIG Welder is a MIG / gas with a maker-stated output of up to 200 amps on 220-volt input.
By Miller's rule of thumb of 1 amp per 0.001 inch of steel, 200 amps reaches about 0.200 in in a single pass. Amps by thickness.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Processes, per the maker: MIG, Gasless Flux Core, Lift TIG. Most multi-process machines' TIG is DC lift-arc, so no aluminium unless AC is stated. Choosing a process.
It runs solid wire under shielding gas (Gasless) for the cleanest wire-feed welds; most machines like it also run flux-core wire outdoors.
Plan a 240-volt circuit sized as the manual states before it arrives. What input voltage changes.
Use a lens of at least OSHA's minimum shade for the current: shade 10 or darker for typical MIG work here. Shade chart.
Also on the listing: dimensions of 14.9 x 5.3 x 9.7 inches and a weight of 32.8 lb.
Warranty, per the listing: 2-Year Manufacturer.
Is it the right machine for the job?
Buy it for
- Clean steel welds indoors
- Steel to about 0.200 in per pass
Skip it for
- Steel much past 0.200 in in one pass
What it does well, where it falls short
Does well
- Up to 200 A output
- Pulse: Pulse MIG
Falls short
- Duty cycle not stated with amps
- Needs a 240 V circuit
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | MIG200P | Retailer |
|---|---|---|
| Product weight | 32.8 lb | Retailer |
| Dimensions (seller) | 14.9 x 5.3 x 9.7 inches | Retailer |
| Size | MIG Welder 200A with Pulse | Retailer |
| Material | ABS+Metal | Retailer |
| Power | ac_dc | Retailer |
| Input power | 220 V | Retailer |
| Warranty | 2-Year Manufacturer | Retailer |
| Output range | 200a | Retailer |
| Processes | MIG, Gasless Flux Core, Lift TIG | Retailer |
| Pulse | Pulse MIG | Retailer |
| Spool gun | spool gun | Retailer |
| Shielding gas | Gasless | Retailer |
Machines to put next to it
Other mig and flux-core welders in the same amp range
- Lincoln Electric K5256-1 MIG Welder
- ESAB ROGUE EM125 MIG Welder
- Lincoln Electric K5387-9 MIG Welder
- Eastwood 180 MIG Welder
Every mig and flux-core welders on one spec sheet · All ARCCAPTAIN machines listed
Final verdict
Made for clean steel welds indoors.
