What it welds
The Lincoln Electric K6080-1 Flux-Core Welder is a flux-core only with a maker-stated output of 20 to 211 amps on 230-volt input.
Miller's starting rule, 1 amp for each 0.001 inch of steel, puts 211 amps at roughly 0.211 in of steel in one pass; thicker work means bevels and more passes. Run the amperage selector.
The maker's thickness claim reads "up to 3/8 in". Makers often mean multiple passes or flux-core wire when a claim runs past the amps rule; the wording here says which.
The listing doesn't give a duty cycle with its amperage, which makes long beads hard to plan; the rating plate or manual should state it. Why it matters.
Wire sizes, per the maker: 0.025-0.045 in. Miller's table puts.030 inch at 40 to 145 amps and.035 inch at 50 to 180 amps.
As a flux-core machine it runs self-shielded wire with no gas bottle, which suits outdoor work; expect slag to chip off and less finesse on thin sheet.
It needs a 240-volt circuit; have a licensed electrician install the receptacle the manual specifies. 120 V vs 240 V.
Eye protection: OSHA's minimum is shade 10 for most of this machine's range. Full table.
Also on the listing: dimensions of 22 x 10.75 x 15.5 inches and a weight of 41 lb.
Is it the right machine for the job?
Buy it for
- Outdoor and gasless repairs
- Steel to about 0.211 in per pass
Skip it for
- Steel much past 0.211 in in one pass
- Aluminium
What it does well, where it falls short
Does well
- Up to 211 A output
- No gas bottle needed
Falls short
- Duty cycle not stated with amps
- Needs a 240 V circuit
- Slag cleanup
Power and setup notes
- Ratings are the maker's own, stated under the maker's conditions. Follow the manual, wear eye protection of at least OSHA's minimum shade, keep combustibles away, ventilate, and have a licensed electrician install new circuits.
Rated output and specs
Every figure below comes from the source shown in brackets. Where the maker doesn't state something, we say so instead of estimating.
| Model number | K6080-1 | Retailer |
|---|---|---|
| Dimensions (seller) | 22 x 10.75 x 15.5 inches | Retailer |
| Product weight | 41 lb | Retailer |
| Output range | 20-211 a | Retailer |
| Duty cycle | 30% duty cycle at 175 A | Retailer |
| Input power | Dual-Voltage 120/230 V | Retailer |
| Max steel (maker) | up to 3/8 in | Retailer |
| Wire sizes | 0.025-0.045 in | Retailer |
Machines to put next to it
Other mig and flux-core welders in the same amp range
- Sunstac SS-180M MIG Welder
- YESWELDER YWM-200 MIG Welder
- Taskzoom TZ005-MIG165-1P-U1 MIG Welder
- VEVOR MIG-200AU MIG Welder
Every mig and flux-core welders on one spec sheet · All Lincoln Electric machines listed
Final verdict
Made for outdoor and gasless repairs.
